Kohler (Now Rehlko) 180kW Generator (Genset) – Model KG180

Standby Range (kW/kVA) 105-180/105-225

Fuel Type Natural Gas | LPG | Dual Fuel

Frequency 60 Hz

Speed 1800 RPM

Alternator Type 4-Pole, Rotating-Field

Engine Manufacturer Rehlko

Standard Features

Rehlko provides one-source responsibility for the generating system and accessories.

The generator set and its components are prototype-tested, factory-built, and production-tested.

The 60 Hz generator set offers a cULus listing.

The generator set accepts rated load in one step.

The 60 Hz generator set meets NFPA 110, Level 1, when equipped with the necessary accessories and installed per NFPA standards.

A one-year limited warranty covers all generator set systems and components. Two- and five-year extended limited warranties are also available.

Natural gas, LP gas, and dual fuel models are available.

Dual Fuel Model Features

Natural gas is the primary fuel. Automatically transfers back to primary fuel when LPG fuel becomes low or generator stops and restarts.

The patented reset box on the generator provides the ability to manually transfer back to natural gas.

The natural gas rating is available when running on natural gas.

APM603 controller provides load shed for automatic derate to LPG ratings to prevent an overload condition.

Alternator Features

The unique Fast-Response® X excitation system delivers excellent voltage response and short-circuit capability using a rare-earth, permanent magnet (PM)-excited alternator. (For 4S12X and 4S13X Alternators)

The unique Fast-Response® II excitation system delivers excellent voltage response and short-circuit capability using a permanent magnet (PM)-excited alternator.(For 4UA13 Alternators)

NEMA MG1, IEEE, and ANSI standards compliance for temperature rise and motor starting.

Sustained short-circuit current of up to 300% of the rated current for up to 10 seconds.

Sustained short-circuit current enabling downstream circuit breakers to trip without collapsing the alternator field.

Windings are vacuum-impregnated with epoxy varnish for dependability and long life.

Contact us at sales@nativeinstinct.com for a quote or if you have questions about your project. Ready to order? Call us at 1-833-354-3356.
